| TRANS-TEC MACHINE EQUIPMENT LIST | ||||||||
|---|---|---|---|---|---|---|---|---|
| TYPE | Machine Info | QT | Travels | Accessory | Acc Feature | Tools | Spec Features | Image |
| CNC LATHE | ||||||||
| CNC LATHE | IKEGAI TU 30 | 1 | X=25” Z=60” | 15” CHUCK | 3.5” HOLE THRU SPINDLE | 12 Tool Turret |  |
|
| CNC LATHE | DAEWOO PUMA 6S | 1 | X=14.1” Z=16.6” | 6” CHUCK | 1.5” HOLE THRU SPINDLE | 12 TOOL TURRET | COLLETS |  |
| CNC LATHE | MORI-SEIKI SL35B | 1 | X=18” Z=35” | 12” CHUCK | 3.625” HOLE THRU SPINDLE | 10 TOOL TURRET |  |
|
| CNC LATHE | MORI-SEIKI SL25B | 2 | X=20.5” Z=24.6” | 10” CHUCK | 2.625” HOLE THRU SPINDLE | 10 TOOL TURRET | COLLETS, PARTS CATCHER |  |
| CNC LATHE | HWACHEON MEGA-100 | 1 | X=38” Z=120” | 28” CHUCK | 10.2” HOLE THRU SPINDLE | 10 TOOL TURRET |  |
|
| CNC LATHE | HWACHEON HI-ECO 45 | 1 | X=37” Z=78.7” | 21” CHUCK | 4.6” HOLE THRU SPINDLE | 12 TOOL TURRET |  |
|
| CNC LATHE | MORI-SEIKI SL-3 | 1 | X=12.6” Z=22” | 10” CHUCK | 4” HOLE THRU SPINDLE | 8 TOOL TURRET | |
|
| CNC LATHE LIVE TOOLS | HARDINGE CONQUEST T-42C | 1 | X=6.37” Z=16” Y=6” | 6” CHUCK | 1.89”HOLE THRU SPINDLE | 16 TOOL TURRET | LIVE TOOLING,SUB SPINDLE,BAR FEEDER |  |
| CNC LATHE | MORI SEIKI TL-3 | 1 | X=18” Z=22.5” | 10” CHUCK | 4” HOLE THRU SPINDLE | 8 Tool Turret |  |
|
| CNC MILL | ||||||||
| CNC MILL | DAH-LIH MCV-2100 | 1 | X=83” Y=33” Z=30” | KITAGAWA 16” 4TH AXIS CHUCK | 6” HOLE THRU CHUCK | 30 TOOL CHANGER |  |
|
| CNC MILL | KASUGA MRK-55 | 1 | X=40” Y=20” Z=18” | NIKKEN 10” 4TH AXIS | 4” HOLE THRU CHUCK | 21 TOOL CHANGER |  |
|
| CNC MILL | FADAL VMC 4020HT | 3 | X=40” Y=20” Z=20” | FADAL 8” 4TH AXIS | 1.75”HOLE THRU CHUCK | 21 TOOL CHANGER |  |
|
| CNC MILL | FADAL VMC 3016 HT | 1 | X=30” Y=16” Z=20” | FADAL 8” 4TH AXIS | 1.75”HOLE THRU CHUCK | 21 TOOL CHANGER |  |
|
| CNC MILL | SUPERMAX MAX 8 REBEL | 1 | X=65” Y=30” Z=30” | KITAGAWA 15” 4TH AXIS | 4” HOLE THRU CHUCK | 30 TOOL CHANGER |  |
|
| CNC MILL | DOOSAN MV-3016LD | 2 | X=30” Y=16” Z=20” | KITAGAWA 8” 4TH AXIS | 1.75”HOLE THRU CHUCK | 20 TOOL CHANGER | CHIP BLASTER HP COOLANT |  |
| CNC MILL | DOOSAN DNM-400 | 1 | X=30” Y=17” Z=20” | KITAGAWA 8” 4TH AXIS | 1.75”HOLE THRU CHUCK | 30 TOOL CHANGER | CHIP BLASTER HP COOLANT |  |
| CNC MILL | MORI-SEIKI MV-55 | 1 | X=41” Y=21” Z=21” | TSUDAKOMA 12” 4TH AXIS | 4” HOLE THRU CHUCK | 24 TOOL CHANGER |  |
|
| CNC MILL | MORI-SEKI MDL MV-65 | 1 | X=60” Y=30” Z=30” | NIKKEN 12” 4TH AXIS | 4” HOLE THRU CHUCK | 30 TOOL CHANGER |  |
|
| CNC MILL | KURAKI HMC-400 | 1 | X=23” Y=11” Z=11” | 15” TWIN PALLET SHUTTLE | 800 LB CAPACITY | 20 TOOL CHANGER |  |
|
| CNC MILL | MORI-SEIKI SH-63 HBM | 1 | X=33” Y=30” Z=33” | 25”TWIN PALLET SHUTTLE | 2,600 LB CAPACITY | 60 TOOL CHANGER | HP COOLANT |  |
| CNC MILL | DOOSAN DHC-400 DS HBM | 1 | X=23” Y=22” Z=22” | 15” TWIN PALLET SHUTTLE | 881 LB CAPACITY | 40 TOOL CHANGER | CHIP BLASTER HP COOLANT |  |
| CNC MILL | 2019 HASS UMC750SS | 1 | X=30" Y=20" Z=20" 19.7” Platter Dia. 360 Deg. C-axis rotation 120 deg. to -35 deg. B-axis tilt 40-taper 40-pos. ATC |
5 Axis | Trunnion Style | 40-pos. ATC |  |
|
| EDM | ||||||||
| EDM | CHARMILLES ROBOFIL 310 | 1 | X=15.7” Y=9.8” Z=15.75” | 30 DEG TAPER ANGLE | X=33.5” Y=19.7” Z=15.75” | .004”-.012” WIRE | 4 AXIS X,Y,U,V |  |
| EDM | CHARMILLES ROBOFIL 290 | 1 | X=15.7” Y=9.8” Z=7.8” | 30 DEG TAPER ANGLE | X=33.5” Y=19.7” Z=15.75” | .004”-.012” WIRE | 4 AXIS X,Y,U,V |  |
| EDM | CHARMILLES ROBOFIL 330F | 2 | X=15.7” Y=11.8” Z=15.7” | 30 DEG TAPER ANGLE | X=29” Y=21” Z=15.75” | .004”-.012” WIRE | 4 AXIS X,Y,U,V SUBMERSIBLE |  |
| EDM | CHARMILLES ROBOFORM 550 | 1 | X=23.6” Y=15.7” Z=17.7” | “C” AXIS | TABLE 29.5” X 23.75” | LINEAR TOOL CHANGER |  |
|
| EDM | CHARMILLES ROBOFORM 50 | 1 | X=23.6” Y=15.7” Z=17.7” | “C” AXIS | TANK 48” X=34” Y=18” | 6 TOOL CHANGER |  |
|
| EDM | CHARMILLES ROBOFORM 22 | 1 | X=11.8” Y=9.8” Z=9.8” | 5TH ROTARY AXIS | TANK 37” X=20.9” Y=13” | “C” AXIS 4 TOOL CHANGER |  |
|
| EDM | CHARMILLES ROBOFORM 23 | 1 | X=13.78” Y=9.8” Z=9.8” | 5TH ROTARY AXIS | TANK 31.5” X=21.6” Y=14” | “C” AXIS 4 TOOL CHANGER |  |
|
| EDM | GENSPARK AMERICA CY1050 | 1 | TANK 55” X=39” Y-20” | 3R TOOLING SYSTEM |  |
|||
| EDM | CHARMILLES HD 30 CNC | 1 | X=11.8” Y=7.87” Z=11.81” W=3.93” | TABLE 15.74” X 11.81” | TANK 28.7” X 18.5” | MANUAL “W” AXIS | HOLE POPPER |  |
| EDM | CHEVALIER ED-252 | 1 | X=11.8” Y=7.9” Z=7.9” | DIGITAL READOUT | TANK 29” X=19” Y=9” | 3R TOOLING SYSTEM |  |
|
| EDM | EASCO PHOENIX 130 | 1 | X=12” Y=6” Z=8” | DIGITAL READOUT | TANK 27” X=14” Y=13” | 3R TOOLING SYSTEM |  |
|
| EDM | JAPAX SDX30NC | 1 | X=12” Y=8” Z=8” | WORK AREA X=11.81” Y=9.84” | .008”-.187” DIA | EDM DRILL |  |
|
| EDM | UNITEK | 1 | X=19” Y=26” Z=21” | WORK AREA X=11.81” Y=9.84” | DISINTEGRATOR |  |
||
| LASERS | ||||||||
| LASER WELDER | ALFA-LASER ALM 200 | 1 | X=4.7” Y=4.7” Z=19.6”-59” BELOW ELBOW | STERO MICROSCOPE 14X | RADIAL SWING BELOW ELBOW=55” RADIUS | MOTORIZED JOYSTICK X-Y-Z POSITION CONTROL | DEEP PENETRATING LASER PLASMA WELDER |  |
| LASER PART MARKER | JIMANI FLFB60 LASER MARKING SYSTEM | 1 | 4.7S” SQUARE TO 12” SQUARE Z=19” | 1.5X REVERSIBLE BEAM EXPANDER | ROTARY 4TH AXIS | FOOTSWITCH FOR HANDS FREE OPERATION | PROLASE 10 LASER MARKING SOFTWARE |  |
| MANUAL MILL | ||||||||
| MANUAL MILL | SEIKI | 1 | X=30” Y=16” Z=5” | DIGITAL READOUT | VERTICAL KNEE 16” | R8 COLLET |  |
|
| MANUAL MILL | BRIDGEPORT SERIES II | 1 | X=33” Y=15” Z=5” | DIGITAL READOUT | VERTICAL KNEE 16” | R8 COLLET | W/8” RISER BLOCK |  |
| MANUAL MILL | BRIDGEPORT | 1 | X=30” Y=9” Z=5” | DIGITAL READOUT | VERTICAL KNEE 16” | R8 COLLET |  |
|
| MANUAL MILL | REPUBLIC LAGUN | 1 | X=30” Y=9” Z=5” | DIGITAL READOUT | VERTICAL KNEE 16” | R8 COLLET |  |
|
| MANUAL MILL | SHARP | 2 | X=50” Y=10” Z=6” | DIGITAL READOUT | 22” POWERED SPINDLE NOSE T | 40 TAPER TOOL HOLDER | ACU-RITE PROGRAMMABLE CONTROL |  |
| MANUAL LATHE | ||||||||
| MANUAL LATHE | MAZAK 30-120 | 1 | 30” X 120” | DIGITAL READOUT | 4” HOLE THRU CHUCK | TAPER ATTATCHMENT 40” GAP BED |  |
|
| MANUAL LATHE | SHARP 2680C | 2 | 26” X 80” | DIGITAL READOUT | 4.5” HOLE THRU CHUCK | TAPER ATTATCHMENTS |  |
|
| MANUAL LATHE | HWACHEON LATHE | 1 | 21” X 60” | DIGITAL READOUT | 3” HOLE THRU CHUCK | TAPER ATTATCHMENTS 29.5” GAP BED |  |
|
| MANUAL LATHE | LEBLONDE LATHE | 1 | 19” X 78” | DIGITAL READOUT | 3” HOLE THRU CHUCK | TAPER ATTATCHMENTS |  |
|
| MANUAL LATHE | HARDINGE PRECISION HL V2 | 2 | 8.5” X 36” | DIGITAL READOUT | 1” HOLE THRU CHUCK | TAPER ATTATCHMENTS |  |
|
| MANUAL LATHE | HARDINGE PRECISION DSM | 1 | 8.5” X 16” | 1” HOLE THRU CHUCK |  |
|||
